Name: 230V LCD Tig Ac Dc Mma Welding Machine Aluminum Welder
Brand: Beijing Aland Welding Co., Ltd.
Availability: InStock

Home Products AC DC TIG Machine

230V LCD Tig Ac Dc Mma Welding Machine Aluminum Welder

Product Details:

Place of Origin:	Beijing, China
Brand Name:	TrustMIG

Contact Now

Detailed Product Description

Material / Metal Processed:	Carbon Steel, Stainless Steel, Aluminium Alloy	Rated Input Voltage:	220 V
Max. Load Power Capacity:	9.2KVA	Output Polarity:	AC/DC TIG
Rated Duty Cycle @40°c (tig):	60%	Rated Output Voltage:	220 V
Welding Current/Voltage Range:	TIG: 5-250A, MMA: 5-200A	Condition:	New
Pulse Frequency:	50-60Hz	Motor Type:	DC MOTOR
Dimensions:	560240460mm	Usage:	PULSE AC DC TIG MMA Welding
Warranty:	1 Year	Weight (kg):	28
Feature:	High Quantity	Plug Type:	US PLUG, European Plug, British Plug, Australian Plug
Rated Output Current:	250A	Welding Thickness:	25mm, 10mm, 5mm, 20mm
Product Name:	IGBT Inverter Pulse AC DC TIG Welder Digi TIG250 AC DC PULSE LCD	Color:	As Requested
Functions:	PULSE AC DC TIG MMA	Other Functions:	SPOT, MIX, REMOTE
Current Range:	TIG: 5-250A, MMA: 5-200A	Max. Load Power Capacity:	4.6KVA
110V 220V Dual Voltage:	Optional	Rate Duty Cycle:	60%
MIX TIG:	Yes	LCD Display:	Yes

IGBT Inverter DC MMA ACTIG DCTIG PULSE TIG 3 IN 1 Welder DIGI-TIG 250AC DC PULS LCD

Product Description

What can you expect from our DIGI-TIG 250AC DC PULS LCD?

Functions: PULSE TIG, AC TIG, DC TIG, DC MMA

Suitable Material: All ferrous metals copper, Aluminium , titanium, stainless steel, and welding in all position.

Features:

1. Pulse MIG/Pulse TIG/Synergic MIG/MMA 3IN1 multi-process
2. Lift-TIG
3. IGBT technology
4. Full Digital Control Panel, Friendly Operation Panel
5. MIG has synergic function that automatically adjusts the wire speed when increases or decreases the voltage.
6. Hot Arc Start, arc force, anti-stick function.
7. 2T/4T function
8. Microprocessor inside, 10 channels memory to facilitate saving time and save your settings favorites.
9. Quickly gas connector, Easy Operation.
10. Over thermal and Current Protection.
11. 10kg/200mm wire spool.
12. Spool Gun socket optional.

Included Accessories:

TIG Torch 3m

Regulator

Gas hose 2m

300A Earth Clamp 3m

300A Electrode Holder 3m

Foot peda

Main Parameters:

MODEL					Digi-TIG250ACDC PULSE LCD
INPUT	Voltage			1xAC220V 50/60Hz
TIG	No-load Voltage			70V
		welding/start/end current Adjusting Range			DC: 2~250A AC: 3~250A
		Rated Output Current			250A
		up slope time adjusting Range			0-30s
		down slope time adjusting Range			0-60s
		pulse freq.			0.1~999.9Hz@DC 0.1~500Hz@SQUARE 0.1~10Hz@AC SINE-T, AC TRIANGULAR， AC SINE WAVE，TRAPEZIUM WAVE
		base/pulse ratio(P. time)			5~95%
		BASE AMPS(base/pulse amps,P.AMP)			3~95%
		AC freq.			20~400Hz
		AC Balance			5~70%
		AC WAVE			SQUARE/SINE-T/ TRIANGULAR/SINE/TRAPEZIUM
		AMPLITUDE	EN-	3-250A
		AMPLITUDE		EP+	10~125%
		Rated Duty Cycle			60%
		TIG Arc starting mode			high frequency/LIFT/LIVE arc striking
Advanced PULSE TIG	AC peak Current			20~250A
		DC AMPS			3~100%
		Pulse time on(P. time)			5%~95%
		pulse (AC to DC-) Freq.			0.1~10Hz
MMA	No-load Voltage			70V
		current Adjusting Range			10~200A
		Rated Output Current			200A
		AC freq.			20~400Hz
		AC Balance			5~70%
		Arc force			0~100%
		hot start current			0~100%
		hot start time			0~2S
		Rated Duty Cycle			60%
Pre gas Flow Time					0~30s
Post gas Flow Time					0~60s
Spot time					0.1~10S
Stitch time					0~5S
Efficiency					≥80%
Protection Class of enclosure					IP21S

Related Products:

Company Introduction

FAQ.

Q1. Why Choose us?

- We have nearly 10 years experience in welding industry and export to all over the world. - We have experienced R&D team. We can adjust the parameter and panels design as per your request.

- Most of key parts are adopted top brand to ensure the quality. Such as the IGBT of Infineon (Simens). - Each machine will be inspected before shipping. - One year warranty, life-long technical support and design service.
Q2. Could you get a customized sample?
Yes, we can adjust some configuration and parameters as your request.

It also includes OEM service.

Q3. How is your quality control?
We use the world-class quality inspection to make every machine strong, powerful and reliable. We inspect with the world class quality testing to make every single machine strong, powerful and reliable.
Inpection is full range, covered from welding power source to wire feeders, welding torches and up to welding consumables and work safety. Whether you want to weld with 2T/4T, GAS/NO GAS, our components, which have been perfectly tuned to your requirements, acting as excellent quality and the best possible welding results.
Q4. What voltage could you provide?

110V/220v, 220/380V, 230V etc.

We can make it as per your country voltage.

Q5. Can you send me the video to show how the machine works?
At present, some machines have video. We will try to make video of featured machine in future.
Q6. Do you have engineer who can guide me to install system?
Yes, we have a professional team. They can teach you how to work with it.
Q7. How long is the lead time for welding machine?
If no stockes, usually it takes 30-35 days after confirmation of order.
