Name: 380v Multifunctional Mig Welders MIG Aluminum Double Pulse Pulse TIG DC MMA MIG Welding Machine
Brand: Beijing Aland Welding Co., Ltd.
Availability: InStock

Home Products GMAW(MIG/MAG) Welding Machine

380v Multifunctional Mig Welders MIG Aluminum Double Pulse Pulse TIG DC MMA MIG Welding Machine

Product Details:

Place of Origin:	Beijing, China
Brand Name:	ALANDWELDING

Contact Now

Detailed Product Description

Material / Metal Processed:	Aluminium Alloy	Rated Input Voltage:	400 V
Wire Melting Type:	Globular Transfer	Max. Load Power Capacity:	27kva
Rated Output Current:	38A	Rated Output Voltage:	400 V
Welding Current/voltage Range:	20-500A	Rated Duty Cycle @40°c (mig):	60%
Wire Feeding Speed:	15 M/min	Condition:	New
Dimensions:	670290560mm	Usage:	Welding All Kinds Of Ferrous Metals
Weight (kg):	52 KG	Warranty:	1 Year
Feature:	INVERTER	Welding Voltage:	14V 3V~50V 3V Use The Voltage Adjusting Knob
Crater Mode:	2Tor4T	Gas Type:	80%Ar+20%CO2(Fe,Cu) ;100%Ar(AlSi,AlMg) ; 98%Ar+2%CO2or O2(CrNi)
Insulation Class:	F	Protection Class Of Shell:	Fan Cooling
Protection Class Of Enclosure:	IP21S	Efficiency:	80%
Key Selling Points:	Easy To Operate	Applicable Industries:	Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Home Use, Retail, Construction Works , Energy & Mining, Other
Machinery Test Report:	Not Available	Video Outgoing-inspection:	Not Available

Features

DIGITAL PULSEMIG350D, 500D SERIES

1. Digital Control DC MMA,Pulse TIG and Double-Pulse Mig

2. IGBT inverter soft switch

3. Syergice mig /pulse mig

4. Over current and over hot protection

5.Special design trolley

6. 2T/4T function

7. Two knobs adjusting

8. 4Rolers wire feeder

9. Material chosen

10. Co2 ,Mix and Argon gas

Product Paramenters

MODEL			PULSEMIG500D
INPUT	Voltage	3*AC380~415V 50Hz/60Hz
		Rated input current	21A
		Rated input power	15KVA
DC MMA	No-load Voltage	60V
		current Adjusting Range	20~350A
		Rated Output Current	350A
		Start Current	0-200A
		Arcforce Current	0-200A
		Rated Duty Cycle	60%
CO2	No-load Voltage	60V
		Rated Duty Cycle	60%
		Current Adjusting Range	20~350A
		Rated Output Current	350A
		crater-fill voltage	14-40V
		crater-fill current	10-350A
		burnback time	0.01-0.5S
		burnback voltage	10.0-25.0V
		Wire Alloy Material	--
		Synergic MIG Or BASIC MIG	all
		crater mode	2T( no Start Current & no crater curent) or 4T( no Start Current),no S4(special 4 step)
		gas type	CO2 or Ar
PULSE MIG	Welding Current	20-500A
		Welding Voltage	-5.0~+5.0
		Rated Output Current	500A
		Rated Duty Cycle	60%
		Start(Initial) Current	10-500A
		Start(initial) Voltage	-5.0~+5.0
		crater-fill voltage	-5.0~+5.0
		crater-fill current	10-500A
		burnback time	0.01-0.5S
		burnback voltage	-5.0~+5.0
		Wire Alloy Material	Fe,AISi,AIMg,CrNi,Cu
		Synergic MIG or BASIC MIG	only Synergic MlG
		crater mode	2T( no Start Current & no crater curent) or 4T( no Start Current) or S4 (special 4 step)
		gas type	80%Ar+20%C02,(Fe,Cu);100%Ar(AISi,AIMg) ;98%Ar+2%CO,or O2(CrNi)
INPUT	Voltage	3*AC380~415V 50Hz/60Hz
DOUBLE PULSE MIG	PULSE peak Current	10~500A
		PULSE peak Voltage	-5.0~+5.0
		Welding(base) Current	10~500A
		Welding(base) Voltage	-5.0~+5.0
		mixed frequency	0.1-9.9Hz
		mixed ratio	10-90%
		Start(initial) Current	10-500A
		Start(Initial) Voltage	-5.0~+5.0
		crater-fill voltage	-5.0~+5.0
		crater-fill current	10-500A
		Rated Duty Cycle	60%
		Rated Output Current	500A
		Wire Alloy Material	Fe,AISi,AIMg,CrNi,Cu
		Synergic MIG or BASIC MIG	only Synergic MIG
		crater mode	2T( no Start Current & no crater current)or 4T( no Start Current)or S4(special 4 step)
		gas type	80%Ar+20%CO2(Fe,Cu);100%Ar(AISi;,AIMg);98%Ar+2%CO2 or O2(CrNi)
CO2 or MIG	inductance	1~10
		Pre gas Flow Time	0~3s
		Post gas Flow Time	0~20s
		Wire Diameter	0.8,1.0,1.2,1.6(solid/flux）
Efficiency			≥80%
Protection Class of enclosure			IP21S
Insulation class			F
Protection class of shell			fan cooling

Product Advantages Introduction

Portable Design

Portable handheld design makes welding more convenient

Digital Display

The welding machine panel design is simpler, digital display data, and current and voltage control are more accurate.

External Wire Feeder

The external wire feeder makes the welding machine more stable when performing high-power welding operations.

Beijing Aland Welding Co., Ltd. is a professional manufacturer and exporter of high quality welding products and welding
solutions.We are proud to provide One Stop Solution for All Your Welding Needs.
We have professional factories of welding equipment, high efficiency production line and high-precision testing equipment,talented workers, and strict quality management
Quality First and Enjoy Work is our company principle.
We recognized that the pursuit of better quality and continuous Innovation is vital to improve competitiveness and obtain business
success. Most of our products have gotten CE, GS and other suitable certificate. We always provide our customers -Quality
Products, Competitive Price, On-time Delivery and Excellent Services.
Our products have been exported to market of Europe, North/South America, Southeast Asia
Oceania, Africa. We are Aland Welding, your reliable parner for Quality Welding! We are willing to grow up and develop with you together.
