Name: Single Phase 3IN1 200A AC DC TIG MMA CUT Welders Aluminum TIG Welders With 2T 4T and Advanced Wave Selection
Brand: Beijing Aland Welding Co., Ltd.
Availability: InStock

Home Products Multi-process Machine

Single Phase 3IN1 200A AC DC TIG MMA CUT Welders Aluminum TIG Welders With 2T 4T and Advanced Wave Selection

Product Details:

Place of Origin:	Beijing, China
Brand Name:	ALANDWELDING

Contact Now

Detailed Product Description

Condition:	New	Machine Type:	Multi-process Machine
Warranty:	1 Year	Weight (kg):	26
Voltage:	220V	Current:	32.1A
Rated Capacity:	7.5KVA	Rated Duty Cycle:	60%
Dimensions:	430x200x290MM	Usage:	Welding And Cutting Of Various Metals
Model:	DIGI-MULTI200ACDCPULS	Input Voltage:	1*230V, 50/60Hz
Rate Input Capacity (KVA):	7.5KVA	Rate Input Current (A):	32.1
No-load Voltage:	70	Rate Duty Cycle:	60%
Up/Down Slope Time:	0-10S	Gas Post Flow Time:	0-25S
Pulse Frequency:	0.5-25S	SP Value (balance):	10-90%
Applicable Industries:	Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Home Use, Retail, Construction Works , Other	Showroom Location:	None
Video Outgoing-inspection:	Not Available	Machinery Test Report:	Not Available
Marketing Type:	Ordinary Product	Warranty Of Core Components:	1 Year
Core Components:	Motor	Key Selling Points:	Multifunctional

Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for
producing PET plastic containers and bottles in all shapes.

MODEL			DIGI-MULTI200ACDCPULS
INPUT	Voltage	1 xAC220V~240V 50Hz
DC MMA	No-load Voltage	70V
		Base current Adjusting Range	5~160A
		Rated Output Current	160A
		Rated Duty Cycle	60%
AC TIG	No-load Voltage	70V
		Current Adjusting Range	5~200A
		SP % (AC balance)	10~70
		AC Square Wave Frequency	30~250Hz
		Rated Duty Cycle	60%
DC TIG	Current Adjusting Range	5~200A
DC TIG		Rated Duty Cycle	60%
Standard PULSE TIG	Peak Current	5~200A
		Base/peak Current ratio	5~95%
		Rated Duty Cycle	60%
		Pulse width	5%~95%
		pulse Freq.	0.1~500Hz@DC 0.1~250Hz@AC ADV.SQUARE 0.1~10Hz@AC SOFT.SQUARE&TRIANGULAR&SINE WAVE
Advanced PULSE TIG (MIX)	AC peak Current	5~200A
		DC(base)/AC peak Current Ratio	5~95%
		Rated Duty Cycle	60%
		Pulse width	5%~95%
		pulse (AC to DC-) Freq.	0.1~10Hz
Current UP/Down-slope Time			0~10S
Initial current/welding current			5~150%
crater-fill current/welding current			5~95%
Pre gas Flow Time			0~25s
Post gas Flow Time			0~25s
Arc starting Mode			HF/LIFT TIG
CUT	current Adjusting Range	20~50A
		Rated Duty Cycle	60%
		Post gas Flow Time	20~60s
Efficiency			≥80%
Mass			26kg
Protection Class of enclosure			IP21S
Outline Dimensions mm3			430x200x290

* Digital Control IGBT inverter DC MMA, Pulse ACDC TIG and CUT
* Lift and HF for TIG
* Hot arc start and arc force, Anti-stick for MMA
* HF or with HF pilot arc for Plasma cutting
* 32 bits MCU inside
* Foot pedal
* 2T/4T function
* Easy Operation and normal selection for TIG parameters.
* AC and DC mix pulse TIG
* Advanced square, soft square, triangular, sine, four AC wave for selection.
* VRD for MMA (Option)
* PFC (Option)
* 10 Memories for selection
