| Condition: | New | Type: | Multi Function Welding Machine |
|---|---|---|---|
| Arc Current: | 38 | Pulse Frequency: | 50/60HZ |
| Pilot Arc Current: | 5-200A | Rated Duty Cycle: | 35% |
| Motor Type: | AC DC MOTOR | Dimensions: | 600*290*480mm |
| Usage: | DC MMA ACDC TIG And MIG | Voltage: | 230V |
| Weight (kg): | 28 KG | Warranty: | 1 Year |
| Voltage: | 1*230V 50/60Hz | Rated Input Current: | 38 A |
| Rated Input Power: | 7KVA | Pre Gas Flow Time: | 0~10s |
| Post Gas Flow Time: | 0~10s | Efficiency: | ≥80% |
| Mass: | 30 | Protection Class Of Enclosure: | IP21S |
| Video Outgoing-inspection: | Not Available | Machinery Test Report: | Not Available |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 1 Year |
| Core Components: | Motor | Key Selling Points: | Multifunctional |
| Applicable Industries: | Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Home Use, Retail, Construction Works , Other | Showroom Location: | None |
Model | MTS200ACDC | MTS250ACDC |
Power Supply Voltage | 1*230V 50/60HZ | 1*230V 50/60HZ |
Rate Input Capacity (KVA) | 7.5 | 8.8 |
Rate Input Current(A) | 38 | 45 |
No Load Voltage | 60/260V | 65/260V |
Output current Range | MIG:30-200A,TIG:10-200A,MMA:10-175A,CUT:20-40A | MIG:30-250A,TIG:5-250A,MMA:10-200A,CUT:20-50A |
Duty Cycle | 35% | 35% |
Weight | 28kg | 35kg |
L*W*H(mm) | 600*290*480 | 600*290*650 |
