Name: 1200W/1500W/2000W/3000W 4 in 1 Laser Double Axis Handheld Welding Laser Machine Water Cooling Laser Welding
Brand: Beijing Aland Welding Co., Ltd.
Availability: InStock

Home Products Laser Welding Machine

1200W/1500W/2000W/3000W 4 in 1 Laser Double Axis Handheld Welding Laser Machine Water Cooling Laser Welding

Product Details:

Place of Origin:	Beijing, China
Brand Name:	ALAND

Contact Now

Detailed Product Description

Condition:	New	Output Power:	1200W,1500W,2000W,3000W
Usage:	Metal Welding,metal Cutting,rust Removal,clean	Wavelength:	1080nm
Focal Spot Diameter:	0.5-3mm	Dimensions:	900600980mm
Warranty:	1 Year	Laser Source Brand:	MAX
Laser Head Brand:	Other	Servo Motor Brand:	Other
Guiderail Brand:	Other	Control System Brand:	Other
Weight (kg):	165 KG	Key Selling Points:	Multifunctional
Model:	FR-LA-1500	Power Supply:	1*220V,50V60Hz
Rate Input Capacity(KVA):	8	Rate Input Current(A):	36
Laser Power:	1500W	Output Power Stability:	2%
Welding Depth Of Fusion:	0.5-3mm	Welding Seam:	≤3mm
Welding Speed:	0-120mm/s	Dia Of Wire:	0.8,1.0,1.2
Applicable Industries:	Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Farms, Home Use, Retail, Construction Works , Other, Advertising Company	Machinery Test Report:	Not Available
Video Outgoing-inspection:	Not Available	Marketing Type:	New Product 2020
Warranty Of Core Components:	1 Year	Core Components:	Bearing, Gear

1. Introduction to welding machine

Laser welding is an efficient and precise welding method that uses high-energy-density laser beams as heat sources. Laser welding is one of the important aspects of the application of laser material processing technology. In the 1970s, it was mainly used for welding thin-walled materials and low-speed welding. The welding process is of the heat conduction type, that is, the laser radiation heats the surface of the workpiece, and the surface heat diffuses to the interior through heat conduction. By controlling the width, energy, peak power and repetition frequency of the laser pulse and other parameters to melt the workpiece and form a specific molten pool. Due to its unique advantages, it has been successfully used in precision welding of micro and small parts.

2. Attribute table

Model	FR-LA-1500	FR-LA-2000	FR-LA-3000
Power Supply	1*220V,50V60Hz	1*220V,50V60Hz	3*380V,50V60Hz
Rate Input Capacity(KVA)	8	9	13
Rate Input Current(A)	36	41	20
Laser power	1500W	2000W	3000W
output power stability	2%	2%	2%
Welding depth of fusion	0.5-3mm	0.5-4mm	0.5-5mm
Welding seam	≤3mm	≤4mm	≤5mm
Welding speed	0-120mm/s	0-120mm/s	0-120mm/s
Dia of wire	0.8,1.0,1.2	0.8,1.0,1.2,1.6	0.8,1.0,1.2,1.6
Weight	165kg	170kg	175kg
LWH(mm)	900600980	900600980	900600980

3. Analysis of product buying points

4. Application scenarios

5. Product configuration

Serial Number	Name	Specification	Quantity
1	Wire feeder	SUP-AMF-A	1
2	Laser nozzle		2
3	Protect lens	0.8/1.0V、1.2V/1.6V、1.2/1.6U	2 each
4	Wire feed nozzle	0.8/1.0/1.2/1.6	1 each
5	Protect glasses	AS-12/AS-20D/BS-16/CS-12/ES-12/FS-16/Cutting/C	1
6	Inner hexagon spanner	D18T2	5
7	Data line		1
8	Tool box		1
9	Wire feed wheel	RS232	1
10	Wire tube		1

6. Buyer comments

7. Company introduction

Beijing Aland Welding Co., Ltd. is a professional manufacturer and exporter of high quality welding products and welding
solutions.We are proud to provide One Stop Solution for All Your Welding Needs.
We have professional factories of welding equipment, high efficiency production line and high-precision testing equipment,
talented workers, and strict quality management
Quality First and Enjoy Work is our company principle.
We recognized that the pursuit of better quality and continuous Innovation is vital to improve competitiveness and obtain business
success. Most of our products have gotten CE, GS and other suitable certificate. We always provide our customers -Quality
Products, Competitive Price, On-time Delivery and Excellent Services.
Our products have been exported to market of Europe, North/South America, Southeast Asia
Oceania, Africa. We are Aland Welding, your reliable parner for Quality Welding! We are willing to grow up and develop with you
together.
