Name: LED Display MMA IGBT Double Pulse Mig 250DC-1 MIG Welder Aluminum
Brand: Beijing Aland Welding Co., Ltd.
Availability: InStock

Home Products Featured Products

LED Display MMA IGBT Double Pulse Mig 250DC-1 MIG Welder Aluminum

Product Details:

Place of Origin:	Beijing, China
Brand Name:	ALAND
Certification:	CCC

Contact Now

Detailed Product Description

Material / Metal Processed:	Aluminium Alloy	Rated Input Voltage:	1 V
Wire Melting Type:	Short Circuit Transfer	Max. Load Power Capacity:	11KVA
Rated Output Current:	20-250A	Rated Output Voltage:	220 V
Welding Current/voltage Range:	20-250A	Rated Duty Cycle @40°c (mig):	60%
Wire Feeding Speed:	3 M/min	Condition:	New
Dimensions:	660290490mm	Usage:	Welding
Weight (kg):	40 KG	Warranty:	1 Year
Feature:	INVERTER	Product Name:	Double Pulse MIG Welding Machine
Color:	Blue Or As Required	OEM:	Available
Input Voltage:	400V	Rated Input Current:	41A
Applicable Wire Diameter:	0.8/1.0/1.2/1.6	Shielding Gas Flow Rate:	10-20l/min
Power:	11KVA	Key Selling Points:	Easy To Operate
Applicable Industries:	Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Farms, Home Use, Retail, Construction Works , Energy & Mining	Machinery Test Report:	Provided
Video Outgoing-inspection:	Not Available

Products Detail

Description: Single Phase 230V Double Pulse CO2 Welding Machine

Model: PulseMIG250DC-1

Model	PULSEMIG250DC-1	PULSEMIG250DC-3
Power Supply Voltage	1*230V 50/60Hz	3*400V 50/60Hz
Rate Input Capacity (KVA)	11	11
Rate Input Current	47.5	15.8
No Load Voltage	80	70
Output Current Range	MIG:20-250A MMA:10-250A	MIG:20-250A MMA:10-175A
Duty Cycle	35%	35%
Weight	36kg	40kg
LWH(mm)	660290490	660290490

■ Digital Control DC MMA, Pulse MIG and Double-Pulse Mig
■ IGBT inverter soft switch
■ Synergice mig /pulse mig
■ Over current and over hot protection.
■ 2T/4T function
■ Two knobs adjusting
■ 4Rollers wire feeder
■Compact style
■ Material chosen, Aluminum Welding.
■Co2 ,Mix and Argon gas

Detailed Image
